I am not able t get any input from the microphone(s) on my system.
Neither the internal microphone nor the microphone on the plugged in earphones with microphone produce any sound.
I have tested with Arecord, Audacity and Krecorder - no sound.
When I plug in the earphones the correct profile pops up.
This is what is shown on pavucontrol, the headphones microphone is detected.
The (lenghty) output of the alsa-info.sh scripts is (run as user):
upload=true&script=true&cardinfo=
!!################################
!!ALSA Information Script v 0.5.3
!!################################
!!Script ran on: Fri Jan 31 14:23:19 UTC 2025
!!Linux Distribution
!!------------------
NAME="openSUSE Leap" ID="opensuse-leap" ID_LIKE="suse opensuse" PRETTY_NAME="openSUSE Leap 15.6" CPE_NAME="cpe:/o:opensuse:leap:15.6" BUG_REPORT_URL="https://bugs.opensuse.org" HOME_URL="https://www.opensuse.org/" DOCUMENTATION_URL="https://en.opensuse.org/Portal:Leap"
!!DMI Information
!!---------------
Manufacturer: FUJITSU CLIENT COMPUTING LIMITED
Product Name: LIFEBOOK E5512
Firmware Version: Version 2.26
System SKU: SK00ICPS
Board Vendor: FUJITSU CLIENT COMPUTING LIMITED
Board Name: FJNB2F4
!!Kernel Information
!!------------------
Kernel release: #1 SMP PREEMPT_DYNAMIC Thu Jan 9 14:10:22 UTC 2025 (ba46628)
Operating System: GNU/Linux
Architecture: x86_64
Processor: x86_64
SMP Enabled: Yes
!!ALSA Version
!!------------
Driver version: k6.4.0-150600.23.33-default
Library version:
Utilities version: 1.2.10
!!Loaded ALSA modules
!!-------------------
snd_soc_skl_hda_dsp (card 0)
!!Sound Servers on this system
!!----------------------------
PipeWire:
Installed - Yes (/usr/bin/pipewire)
Running - Yes
Pulseaudio:
Installed - Yes (/usr/bin/pulseaudio)
Running - Yes
!!Soundcards recognised by ALSA
!!-----------------------------
0 [sofhdadsp ]: sof-hda-dsp - sof-hda-dsp
FUJITSUCLIENTCOMPUTINGLIMITED-LIFEBOOKE5512
!!PCI Soundcards installed in the system
!!--------------------------------------
00:1f.3 Multimedia audio controller [0401]: Intel Corporation Alder Lake PCH-P High Definition Audio Controller [8086:51c8] (rev 01)
Subsystem: Fujitsu Client Computing Limited Device [1e26:0040]
!!Loaded sound module options
!!---------------------------
!!Module: snd_soc_skl_hda_dsp
* :
!!Sysfs card info
!!---------------
!!Card: /sys/class/sound/card0
Driver: /sys/bus/platform/drivers/skl_hda_dsp_generic
!!ALSA Device nodes
!!-----------------
crw-rw----+ 1 root audio 116, 12 Jan 31 12:10 /dev/snd/controlC0
crw-rw----+ 1 root audio 116, 11 Jan 31 12:10 /dev/snd/hwC0D0
crw-rw----+ 1 root audio 116, 10 Jan 31 12:10 /dev/snd/hwC0D2
crw-rw----+ 1 root audio 116, 5 Jan 31 15:17 /dev/snd/pcmC0D0c
crw-rw----+ 1 root audio 116, 4 Jan 31 15:17 /dev/snd/pcmC0D0p
crw-rw----+ 1 root audio 116, 6 Jan 31 12:10 /dev/snd/pcmC0D31p
crw-rw----+ 1 root audio 116, 7 Jan 31 15:17 /dev/snd/pcmC0D3p
crw-rw----+ 1 root audio 116, 8 Jan 31 15:17 /dev/snd/pcmC0D4p
crw-rw----+ 1 root audio 116, 9 Jan 31 15:17 /dev/snd/pcmC0D5p
crw-rw----+ 1 root audio 116, 2 Jan 31 15:17 /dev/snd/pcmC0D6c
crw-rw----+ 1 root audio 116, 3 Jan 31 12:10 /dev/snd/pcmC0D7c
crw-rw----+ 1 root audio 116, 1 Jan 31 12:10 /dev/snd/seq
crw-rw----+ 1 root audio 116, 33 Jan 31 12:10 /dev/snd/timer
/dev/snd/by-path:
total 0
drwxr-xr-x 2 root root 60 Jan 31 12:10 .
drwxr-xr-x 3 root root 320 Jan 31 12:10 ..
lrwxrwxrwx 1 root root 12 Jan 31 12:10 pci-0000:00:1f.3-platform-skl_hda_dsp_generic -> ../controlC0
!!Aplay/Arecord output
!!--------------------
APLAY
**** List of PLAYBACK Hardware Devices ****
card 0: sofhdadsp [sof-hda-dsp], device 0: HDA Analog (*) []
Subdevices: 0/1
Subdevice #0: subdevice #0
card 0: sofhdadsp [sof-hda-dsp], device 3: HDMI1 (*) []
Subdevices: 0/1
Subdevice #0: subdevice #0
card 0: sofhdadsp [sof-hda-dsp], device 4: HDMI2 (*) []
Subdevices: 0/1
Subdevice #0: subdevice #0
card 0: sofhdadsp [sof-hda-dsp], device 5: HDMI3 (*) []
Subdevices: 0/1
Subdevice #0: subdevice #0
card 0: sofhdadsp [sof-hda-dsp], device 31: HDA Analog Deep Buffer (*) []
Subdevices: 1/1
Subdevice #0: subdevice #0
ARECORD
**** List of CAPTURE Hardware Devices ****
card 0: sofhdadsp [sof-hda-dsp], device 0: HDA Analog (*) []
Subdevices: 0/1
Subdevice #0: subdevice #0
card 0: sofhdadsp [sof-hda-dsp], device 6: DMIC (*) []
Subdevices: 0/1
Subdevice #0: subdevice #0
card 0: sofhdadsp [sof-hda-dsp], device 7: DMIC16kHz (*) []
Subdevices: 1/1
Subdevice #0: subdevice #0
!!Amixer output
!!-------------
!!-------Mixer controls for card sofhdadsp
Card sysdefault:0 'sofhdadsp'/'FUJITSUCLIENTCOMPUTINGLIMITED-LIFEBOOKE5512 '
Mixer name : 'Realtek ALC257'
Components : 'HDA:8086281c,80860101,00100000 HDA:10ec0257,1e268b8a,00100001 cfg-dmics:2'
Controls : 43
Simple ctrls : 16
Simple mixer control 'Master',0
Capabilities: pvolume pvolume-joined pswitch pswitch-joined
Playback channels: Mono
Limits: Playback 0 - 87
Mono: Playback 87 [100%] [0.00dB] [on]
Simple mixer control 'Headphone',0
Capabilities: pvolume pswitch
Playback channels: Front Left - Front Right
Limits: Playback 0 - 87
Mono:
Front Left: Playback 80 [92%] [-5.25dB] [on]
Front Right: Playback 80 [92%] [-5.25dB] [on]
Simple mixer control 'Speaker',0
Capabilities: pvolume pswitch
Playback channels: Front Left - Front Right
Limits: Playback 0 - 87
Mono:
Front Left: Playback 77 [89%] [-7.50dB] [off]
Front Right: Playback 77 [89%] [-7.50dB] [off]
Simple mixer control 'IEC958',0
Capabilities: pswitch pswitch-joined
Playback channels: Mono
Mono: Playback [on]
Simple mixer control 'IEC958',1
Capabilities: pswitch pswitch-joined
Playback channels: Mono
Mono: Playback [on]
Simple mixer control 'IEC958',2
Capabilities: pswitch pswitch-joined
Playback channels: Mono
Mono: Playback [on]
Simple mixer control 'Auto-Mute Mode',0
Capabilities: enum
Items: 'Disabled' 'Enabled'
Item0: 'Disabled'
Simple mixer control 'Dmic0',0
Capabilities: cvolume cswitch
Capture channels: Front Left - Front Right
Limits: Capture 0 - 70
Front Left: Capture 64 [91%] [14.00dB] [on]
Front Right: Capture 64 [91%] [14.00dB] [on]
Simple mixer control 'Dmic1 2nd',0
Capabilities: cvolume
Capture channels: Front Left - Front Right
Limits: Capture 0 - 70
Front Left: Capture 50 [71%] [0.00dB]
Front Right: Capture 50 [71%] [0.00dB]
Simple mixer control 'PGA1.0 1 Master',0
Capabilities: pvolume
Playback channels: Front Left - Front Right
Limits: Playback 0 - 32
Mono:
Front Left: Playback 32 [100%] [0.00dB]
Front Right: Playback 32 [100%] [0.00dB]
Simple mixer control 'PGA2.0 2 Master',0
Capabilities: cvolume
Capture channels: Front Left - Front Right
Limits: Capture 0 - 80
Front Left: Capture 50 [62%] [0.00dB]
Front Right: Capture 50 [62%] [0.00dB]
Simple mixer control 'PGA30.0 30',0
Capabilities: pvolume
Playback channels: Front Left - Front Right
Limits: Playback 0 - 32
Mono:
Front Left: Playback 32 [100%] [0.00dB]
Front Right: Playback 32 [100%] [0.00dB]
Simple mixer control 'PGA31.0 31',0
Capabilities: pvolume
Playback channels: Front Left - Front Right
Limits: Playback 0 - 32
Mono:
Front Left: Playback 32 [100%] [0.00dB]
Front Right: Playback 32 [100%] [0.00dB]
Simple mixer control 'PGA7.0 7 Master',0
Capabilities: pvolume
Playback channels: Front Left - Front Right
Limits: Playback 0 - 32
Mono:
Front Left: Playback 32 [100%] [0.00dB]
Front Right: Playback 32 [100%] [0.00dB]
Simple mixer control 'PGA8.0 8 Master',0
Capabilities: pvolume
Playback channels: Front Left - Front Right
Limits: Playback 0 - 32
Mono:
Front Left: Playback 32 [100%] [0.00dB]
Front Right: Playback 32 [100%] [0.00dB]
Simple mixer control 'PGA9.0 9 Master',0
Capabilities: pvolume
Playback channels: Front Left - Front Right
Limits: Playback 0 - 32
Mono:
Front Left: Playback 32 [100%] [0.00dB]
Front Right: Playback 32 [100%] [0.00dB]
!!Alsactl output
!!--------------
--startcollapse--
state.sofhdadsp {
control.1 {
iface MIXER
name 'Headphone Playback Volume'
value.0 80
value.1 80
comment {
access 'read write'
type INTEGER
count 2
range '0 - 87'
dbmin -6525
dbmax 0
dbvalue.0 -525
dbvalue.1 -525
}
}
control.2 {
iface MIXER
name 'Headphone Playback Switch'
value.0 true
value.1 true
comment {
access 'read write'
type BOOLEAN
count 2
}
}
control.3 {
iface MIXER
name 'Speaker Playback Volume'
value.0 77
value.1 77
comment {
access 'read write'
type INTEGER
count 2
range '0 - 87'
dbmin -6525
dbmax 0
dbvalue.0 -750
dbvalue.1 -750
}
}
control.4 {
iface MIXER
name 'Speaker Playback Switch'
value.0 false
value.1 false
comment {
access 'read write'
type BOOLEAN
count 2
}
}
control.5 {
iface MIXER
name 'Auto-Mute Mode'
value Disabled
comment {
access 'read write'
type ENUMERATED
count 1
item.0 Disabled
item.1 Enabled
}
}
control.6 {
iface MIXER
name 'Master Playback Volume'
value 87
comment {
access 'read write'
type INTEGER
count 1
range '0 - 87'
dbmin -6525
dbmax 0
dbvalue.0 0
}
}
control.7 {
iface MIXER
name 'Master Playback Switch'
value true
comment {
access 'read write'
type BOOLEAN
count 1
}
}
control.8 {
iface CARD
name 'Headphone Jack'
value true
comment {
access read
type BOOLEAN
count 1
}
}
control.9 {
iface CARD
name 'Speaker Phantom Jack'
value true
comment {
access read
type BOOLEAN
count 1
}
}
control.10 {
iface CARD
name 'HDMI/DP,pcm=3 Jack'
value false
comment {
access read
type BOOLEAN
count 1
}
}
control.11 {
iface MIXER
name 'IEC958 Playback Con Mask'
value '0fff000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access read
type IEC958
count 1
}
}
control.12 {
iface MIXER
name 'IEC958 Playback Pro Mask'
value '0f00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access read
type IEC958
count 1
}
}
control.13 {
iface MIXER
name 'IEC958 Playback Default'
value '0400000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access 'read write'
type IEC958
count 1
}
}
control.14 {
iface MIXER
name 'IEC958 Playback Switch'
value true
comment {
access 'read write'
type BOOLEAN
count 1
}
}
control.15 {
iface PCM
device 3
name ELD
value ''
comment {
access 'read volatile'
type BYTES
count 0
}
}
control.16 {
iface CARD
name 'HDMI/DP,pcm=4 Jack'
value false
comment {
access read
type BOOLEAN
count 1
}
}
control.17 {
iface MIXER
name 'IEC958 Playback Con Mask'
index 1
value '0fff000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access read
type IEC958
count 1
}
}
control.18 {
iface MIXER
name 'IEC958 Playback Pro Mask'
index 1
value '0f00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access read
type IEC958
count 1
}
}
control.19 {
iface MIXER
name 'IEC958 Playback Default'
index 1
value '0400000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access 'read write'
type IEC958
count 1
}
}
control.20 {
iface MIXER
name 'IEC958 Playback Switch'
index 1
value true
comment {
access 'read write'
type BOOLEAN
count 1
}
}
control.21 {
iface PCM
device 4
name ELD
value ''
comment {
access 'read volatile'
type BYTES
count 0
}
}
control.22 {
iface CARD
name 'HDMI/DP,pcm=5 Jack'
value false
comment {
access read
type BOOLEAN
count 1
}
}
control.23 {
iface MIXER
name 'IEC958 Playback Con Mask'
index 2
value '0fff000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access read
type IEC958
count 1
}
}
control.24 {
iface MIXER
name 'IEC958 Playback Pro Mask'
index 2
value '0f00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access read
type IEC958
count 1
}
}
control.25 {
iface MIXER
name 'IEC958 Playback Default'
index 2
value '0400000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access 'read write'
type IEC958
count 1
}
}
control.26 {
iface MIXER
name 'IEC958 Playback Switch'
index 2
value true
comment {
access 'read write'
type BOOLEAN
count 1
}
}
control.27 {
iface PCM
device 5
name ELD
value ''
comment {
access 'read volatile'
type BYTES
count 0
}
}
control.28 {
iface PCM
device 3
name 'Playback Channel Map'
value.0 0
value.1 0
value.2 0
value.3 0
value.4 0
value.5 0
value.6 0
value.7 0
comment {
access 'read write'
type INTEGER
count 8
range '0 - 36'
}
}
control.29 {
iface PCM
device 4
name 'Playback Channel Map'
value.0 0
value.1 0
value.2 0
value.3 0
value.4 0
value.5 0
value.6 0
value.7 0
comment {
access 'read write'
type INTEGER
count 8
range '0 - 36'
}
}
control.30 {
iface PCM
device 5
name 'Playback Channel Map'
value.0 0
value.1 0
value.2 0
value.3 0
value.4 0
value.5 0
value.6 0
value.7 0
comment {
access 'read write'
type INTEGER
count 8
range '0 - 36'
}
}
control.31 {
iface MIXER
name 'PGA1.0 1 Master Playback Volume'
value.0 32
value.1 32
comment {
access 'read write'
type INTEGER
count 2
range '0 - 32'
dbmin -9999999
dbmax 0
dbvalue.0 0
dbvalue.1 0
}
}
control.32 {
iface MIXER
name 'PGA2.0 2 Master Capture Volume'
value.0 50
value.1 50
comment {
access 'read write'
type INTEGER
count 2
range '0 - 80'
dbmin -9999999
dbmax 3000
dbvalue.0 0
dbvalue.1 0
}
}
control.34 {
iface MIXER
name 'PGA7.0 7 Master Playback Volume'
value.0 32
value.1 32
comment {
access 'read write'
type INTEGER
count 2
range '0 - 32'
dbmin -9999999
dbmax 0
dbvalue.0 0
dbvalue.1 0
}
}
control.35 {
iface MIXER
name 'PGA8.0 8 Master Playback Volume'
value.0 32
value.1 32
comment {
access 'read write'
type INTEGER
count 2
range '0 - 32'
dbmin -9999999
dbmax 0
dbvalue.0 0
dbvalue.1 0
}
}
control.36 {
iface MIXER
name 'PGA9.0 9 Master Playback Volume'
value.0 32
value.1 32
comment {
access 'read write'
type INTEGER
count 2
range '0 - 32'
dbmin -9999999
dbmax 0
dbvalue.0 0
dbvalue.1 0
}
}
control.37 {
iface MIXER
name 'Dmic0 Capture Volume'
value.0 64
value.1 64
comment {
access 'read write'
type INTEGER
count 2
range '0 - 70'
dbmin -9999999
dbmax 2000
dbvalue.0 1400
dbvalue.1 1400
}
}
control.38 {
iface MIXER
name 'Dmic0 Capture Switch'
value.0 true
value.1 true
comment {
access 'read write'
type BOOLEAN
count 2
}
}
control.40 {
iface MIXER
name 'Dmic1 2nd Capture Volume'
value.0 50
value.1 50
comment {
access 'read write'
type INTEGER
count 2
range '0 - 70'
dbmin -9999999
dbmax 2000
dbvalue.0 0
dbvalue.1 0
}
}
control.42 {
iface MIXER
name 'PGA30.0 30 Playback Volume'
value.0 32
value.1 32
comment {
access 'read write'
type INTEGER
count 2
range '0 - 32'
dbmin -9999999
dbmax 0
dbvalue.0 0
dbvalue.1 0
}
}
control.43 {
iface MIXER
name 'PGA31.0 31 Playback Volume'
value.0 32
value.1 32
comment {
access 'read write'
type INTEGER
count 2
range '0 - 32'
dbmin -9999999
dbmax 0
dbvalue.0 0
dbvalue.1 0
}
}
}
--endcollapse--
I do see entries with Dmic (digital microphone?) , but nothing for the analogue microphone in the earphones.
I have looked at the following link, but I could not apply the suggestions to my situation.
https://forums.opensuse.org/t/xfce-no-microphone-input/142569/2
So, any suggestions would be welcomed.
