Hi all,
It’s been a while since the last time I printed in Ledger (11"x17") and legal (8.5x14") size.
I have a drawing that needs to be printed in legal or ledger size but anything I do it prints in letter size (8.5"x11")
Appreciate any help in this problem.
Below is my drawing to be printed.
Below is the result when printing in legal size
This is an old printer I used to print ledger architectural working drawings before and never encountered this problem.
Thanks in advance.
Too late to edit my first post.
I am using tumbleweed with xfce 4.20.
The applications I tried to print are gimp, ristretto and ksnip.
We have a new epson and hp printer but it can’t come closer to the quality that this brother printer can achieve.
This brother prints almost if not perfect very much looks like the original color of the image that appears in my monitor.
Could you show us
lpstat -p -d and lpoptions -p <printer-name> -l output.
Also, what application are you printing from?
If Legal is shown by CUPS but the application still submits the job as Letter, you can try printing directly like this…
lp -d <printer-name> -o media=Legal <test-file>
Any different? (Just trying to understand if an application or CUPS job processing issue.)
Which driver do you use?
egrep -i "|name|model|filter" /etc/cups/ppd/*
(This will spit out ppd information for all currently configured printers.)
@deano_ferrari Thank for the quick reply
Here is the output.
~> lpstat -p -d
printer CUPS-PDF is idle. enabled since Wed 26 Aug 2026 06:33:16 PM EDT
printer EPSON-ET-2800-Series is idle. enabled since Fri 11 Sep 2026 02:11:10 PM EDT
printer MFC5890CN is idle. enabled since Thu 17 Sep 2026 09:04:42 AM EDT
system default destination: MFC5890CN
~> lpoptions -p MFC5890CN -l
PageSize/Media Size: BrA3_S BrA3_A3 BrA3_B_S BrA3_B_A3 B4 BrB4_S BrB4_B_B4 BrB4_B_S Tabloid BrLedger_S BrLedger_B_Ledger BrLedger_B_S A4 BrA4_B *Letter BrLetter_B Legal Executive B5 A5 A6 BrA6_B PostC4x6 BrPostC4x6_B IndexC5x8 BrIndexC5x8_B PhotoL BrPhotoL_B Photo2L BrPhoto2L_B Postcard BrHagaki_B DoublePostcardRotated EnvC5 EnvDL Env10 EnvMonarch EnvYou4 Custom.WIDTHxHEIGHT
BRInputSlot/Paper Source: *AutoSelect Tray1 Tray2
Resolution/Quality: 150x150dpi 300x300dpi *600x600dpi 1200x1200dpi 1200x2400dpi 1200x6000dpi
BRMonoColor/Color/Grayscale: *Color Mono
BRSlowDrying/Slow Drying Paper: *OFF ON
BRColorMediaType/Media Type: *Plain Inkjet BrotherGlossyR BrotherGlossy Glossy Transparencies
BRColorPaperThick/Paper Thickness: *Regular Thick
BRBiDir/Bi-Directional Printing: OFF *ON
BRReverse/Reverse Printing: *OFF ON
BrMirror/Mirror Printing: *OFF ON
BRJpeg/Data Transfer Mode: *Recommended QualityPrior SpeedPrior
BRColorMatching/Color Mode: *Natural Vivid None
BRHalfTonePattern/Halftone Pattern: *Diffusion Dither
BRColorEnhancement/ Color Enhancement(True2Life): *OFF ON
BRBrightness/ Brightness: -20 -19 -18 -17 -16 -15 -14 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 *0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
BRContrast/ Contrast: -20 -19 -18 -17 -16 -15 -14 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 *0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
BRRed/ Red: -20 -19 -18 -17 -16 -15 -14 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 *0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
BRGreen/ Green: -20 -19 -18 -17 -16 -15 -14 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 *0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
BRBlue/Blue: -20 -19 -18 -17 -16 -15 -14 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 *0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
It spit out a long lines of info.
Thelist is like eternity
For the driver I am using the brother supplied linux driver from the brother site.
@deano_ferrari The same result it is still printing in letter size
Ok, so we’ve eliminated an application-specific issues. What file did you use for testing? A JPEG?
Try specifying page size explicitly…
lp -d MFC5890CN -o PageSize=Legal <image-file>
Just to clarify further, when you say it still prints in Letter size, does the printer actually feed a Letter (8.5×11) sheet, or does it feed a Legal (8.5×14) sheet but the image is still laid out as Letter?
For the command lp -d MFC5890CN -o PageSize=Legal <image-file>It didn’t work. The result is the same.
To confirm my printer setup. It feeds a legal size (8.5x14) but print in letter size, the same as the image I posted in my first post.
I already change the printer configuration in the brother printer physical set up to default in legal size. The tray is aligned in the legal size accordingly.
The paper tray feeder has specific adjustments for different kinds of paper size to use in printing.
I already tried printing in jpeg and png.
Thanks.
Does scaling with “fit-to-page” help?
lp -d MFC5890CN -o media=Legal -o fit-to-page <image-file>
or more specifically for landscape
lp -d MFC5890CN -o media=Legal -o fit-to-page -o landscape <image-file>
@deano_ferrari ,
Nothing work. I search the net also and there was one topic saying to change the default paper size in /etc/ups/ppd/brother_model.ppd (in my case MFC5890CN.ppd) by hand. According to that topic it’s a brother printer bug, t didn’t work.
One thing I notice in the MFC890CN.PPD , there is a line that says like so:
VariablePaperSize: False
I tried changing it to true but still no go.
here is the /etc/cups/ppd/MFC5890CN.ppd
*PPD-Adobe: "4.3"
*%================================================
*% Copyright(C) 2006 Brother Industries, Ltd.
*% "Brother MFC-5890CN CUPS"
*%================================================
*%==== General Information Keywords ========================
*FormatVersion: "4.3"
*FileVersion: "1.00"
*LanguageVersion: English
*LanguageEncoding: ISOLatin1
*PCFileName: "BR5890_2.PPD"
*Manufacturer: "Brother"
*Product: "(MFC-5890CN)"
*1284DeviceID: "MFG:Brother;MDL:MFC-5890CN"
*cupsVersion: 1.1
*cupsManualCopies: False
*cupsFilter: "application/vnd.cups-postscript 0 brlpdwrappermfc5890cn"
*cupsModelNumber: 8
*ModelName: "Brother MFC-5890CN"
*ShortNickName: "Brother MFC-5890CN"
*NickName: "Brother MFC-5890CN CUPS v1.1"
*PSVersion: "(3010.106) 3"
*%==== Basic Device Capabilities =============
*LanguageLevel: "3"
*ColorDevice: True
*DefaultColorSpace: RGB
*FileSystem: False
*Throughput: "12"
*LandscapeOrientation: Plus90
*VariablePaperSize: False
*TTRasterizer: Type42
*FreeVM: "1700000"
*%DefaultOutputOrder: Reverse
*%==== UI Constraints ======================
*UIConstraints: *BRColorMediaType Inkjet *BRInputSlot Tray2
*UIConstraints: *BRColorMediaType Glossy *BRInputSlot Tray2
*UIConstraints: *BRColorMediaType BrotherGlossy *BRInputSlot Tray2
*UIConstraints: *BRColorMediaType BrotherGlossyR *BRInputSlot Tray2
*UIConstraints: *BRColorMediaType Transparencies *BRInputSlot Tray2
*%UIConstraints: *BRColorMediaType HagakiAtena *BRInputSlot Tray2
*%UIConstraints: *BRColorMediaType HagakiUra *BRInputSlot Tray2
*%==== Media Selection ======================
*OpenUI *PageSize/Media Size: PickOne
*OrderDependency: 11 AnySetup *PageSize
*DefaultPageSize: Legal
*PageSize BrA3_S/A3: " "
*PageSize BrA3_A3/A3 (Long Grain): " "
*PageSize BrA3_B_S/A3 (Borderless): " "
*PageSize BrA3_B_A3/A3 (Borderless / Long Grain): " "
*PageSize B4/JB4: " "
*PageSize BrB4_S/JB4 (Short Grain): " "
*PageSize BrB4_B_B4/JB4 (Borderless): " "
*PageSize BrB4_B_S/JB4 (Borderless / Short Grain): " "
*PageSize Tabloid/Tabloid: " "
*PageSize BrLedger_S/Tabloid (Short Grain): " "
*PageSize BrLedger_B_Ledger/Tabloid (Borderless): " "
*PageSize BrLedger_B_S/Tabloid (Borderless / Short Grain): " "
*PageSize A4/A4: " "
*PageSize BrA4_B/A4 (Borderless): " "
*PageSize Letter/Letter: " "
*PageSize BrLetter_B/US Letter (Borderless): " "
*PageSize Legal/Legal: " "
*PageSize Executive/Executive: " "
*PageSize B5/JIS B5: " "
*PageSize A5/A5: " "
*PageSize A6/A6: " "
*PageSize BrA6_B/A6 (Borderless): " "
*PageSize PostC4x6/Photo: " "
*PageSize BrPostC4x6_B/Photo (Borderless): " "
*PageSize IndexC5x8/Index Card: " "
*PageSize BrIndexC5x8_B/Index Card (Borderless): " "
*PageSize PhotoL/Photo L: " "
*PageSize BrPhotoL_B/Photo L (Borderless): " "
*PageSize Photo2L/Photo 2L: " "
*PageSize BrPhoto2L_B/Photo 2L (Borderless): " "
*PageSize Postcard/Postcard 1: " "
*PageSize BrHagaki_B/Postcard 1 (Borderless): " "
*PageSize DoublePostcardRotated/Postcard 2 (Double): " "
*PageSize EnvC5/C5 Envelope: " "
*PageSize EnvDL/DL Envelope: " "
*PageSize Env10/Com-10: " "
*PageSize EnvMonarch/Monarch: " "
*PageSize EnvYou4/JE4 Envelope: " "
*CloseUI: *PageSize
*OpenUI *PageRegion: PickOne
*OrderDependency: 12 AnySetup *PageRegion
*DefaultPageRegion: Legal
*PageRegion BrA3_S/A3: " "
*PageRegion BrA3_A3/A3 (Long Grain): " "
*PageRegion BrA3_B_S/A3 (Borderless): " "
*PageRegion BrA3_B_A3/A3 (Borderless / Long Grain): " "
*PageRegion B4/JB4: " "
*PageRegion BrB4_S/JB4 (Short Grain): " "
*PageRegion BrB4_B_B4/JB4 (Borderless): " "
*PageRegion BrB4_B_S/JB4 (Borderless / Short Grain): " "
*PageRegion Tabloid/Tabloid: " "
*PageRegion BrLedger_S/Tabloid (Short Grain): " "
*PageRegion BrLedger_B_Ledger/Tabloid (Borderless): " "
*PageRegion BrLedger_B_S/Tabloid (Borderless / Short Grain): " "
*PageRegion A4/A4: " "
*PageRegion BrA4_B/A4 (Borderless): " "
*PageRegion Letter/Letter: " "
*PageRegion BrLetter_B/US Letter (Borderless): " "
*PageRegion Legal/Legal: " "
*PageRegion Executive/Executive: " "
*PageRegion B5/JIS B5: " "
*PageRegion A5/A5: " "
*PageRegion A6/A6: " "
*PageRegion BrA6_B/A6 (Borderless): " "
*PageRegion PostC4x6/Photo: " "
*PageRegion BrPostC4x6_B/Photo (Borderless): " "
*PageRegion IndexC5x8/Index Card: " "
*PageRegion BrIndexC5x8_B/Index Card (Borderless): " "
*PageRegion PhotoL/Photo L: " "
*PageRegion BrPhotoL_B/Photo L (Borderless): " "
*PageRegion Photo2L/Photo 2L: " "
*PageRegion BrPhoto2L_B/Photo 2L (Borderless): " "
*PageRegion Postcard/Postcard 1: " "
*PageRegion BrHagaki_B/Postcard 1 (Borderless): " "
*PageRegion DoublePostcardRotated/Postcard 2 (Double): " "
*PageRegion EnvC5/C5 Envelope: " "
*PageRegion EnvDL/DL Envelope: " "
*PageRegion Env10/Com-10: " "
*PageRegion EnvMonarch/Monarch: " "
*PageRegion EnvYou4/JE4 Envelope: " "
*CloseUI: *PageRegion
*DefaultImageableArea: Legal
*ImageableArea BrA3_S/A3: "9 9 819 1168"
*ImageableArea BrA3_A3/A3 (Long Grain): "9 9 576 1168"
*ImageableArea BrA3_B_S/A3 (Borderless): "6 6 840 1186"
*ImageableArea BrA3_B_A3/A3 (Borderless / Long Grain): "6 6 840 1186"
*ImageableArea B4/JB4: "9 9 706 1009"
*ImageableArea BrB4_S/JB4 (Short Grain): "9 9 706 1009"
*ImageableArea BrB4_B_B4/JB4 (Borderless): "6 6 727 1030"
*ImageableArea BrB4_B_S/JB4 (Borderless / Short Grain): "6 6 727 1030"
*ImageableArea Tabloid/Tabloid: "9 9 769 1201"
*ImageableArea BrLedger_S/Tabloid (Short Grain): "9 9 769 1201"
*ImageableArea BrLedger_B_Ledger/Tabloid (Borderless): "6 6 790 1222"
*ImageableArea BrLedger_B_S/Tabloid (Borderless / Short Grain): "6 6 790 1222"
*ImageableArea A4/A4: "9 9 576 820"
*ImageableArea BrA4_B/A4 (Borderless): "6 6 595 839"
*ImageableArea Letter/Letter: "9 9 593 770"
*ImageableArea BrLetter_B/US Letter (Borderless): "9 9 615 792"
*ImageableArea Legal/Legal: "9 9 593 986"
*ImageableArea Executive/Executive: "9 9 503 734"
*ImageableArea B5/JIS B5: "9 9 481 687"
*ImageableArea A5/A5: "9 9 401 573"
*ImageableArea A6/A6: "9 9 279 397"
*ImageableArea BrA6_B/A6 (Borderless): "6 6 296 424"
*ImageableArea PostC4x6/Photo: "9 9 269 410"
*ImageableArea BrPostC4x6_B/Photo (Borderless): "6 6 285 436"
*ImageableArea IndexC5x8/Index Card: "9 9 341 554"
*ImageableArea BrIndexC5x8_B/Index Card (Borderless): "6 6 357 580"
*ImageableArea PhotoL/Photo L: "9 9 233 338"
*ImageableArea BrPhotoL_B/Photo L (Borderless): "6 6 251 364"
*ImageableArea Photo2L/Photo 2L: "9 9 340 483"
*ImageableArea BrPhoto2L_B/Photo 2L (Borderless): "6 6 357 509"
*ImageableArea Postcard/Postcard 1: "9 9 264 397"
*ImageableArea BrHagaki_B/Postcard 1 (Borderless): "6 6 280 423"
*ImageableArea DoublePostcardRotated/Postcard 2 (Double): "9 9 401 545"
*ImageableArea EnvC5/C5 Envelope: "9 68 440 686"
*ImageableArea EnvDL/DL Envelope: "9 68 293 661"
*ImageableArea Env10/Com-10: "9 68 275 721"
*ImageableArea EnvMonarch/Monarch: "9 68 260 577"
*ImageableArea EnvYou4/JE4 Envelope: "9 68 278 701"
*%==== Information About Media Sizes ========
*DefaultPaperDimension: Legal
*PaperDimension BrA3_S/A3: "828 1177"
*PaperDimension BrA3_A3/A3 (Long Grain): "585 1177"
*PaperDimension BrA3_B_S/A3 (Borderless): "846 1192"
*PaperDimension BrA3_B_A3/A3 (Borderless / Long Grain): "846 1192"
*PaperDimension B4/JB4: "715 1018"
*PaperDimension BrB4_S/JB4 (Short Grain): "715 1018"
*PaperDimension BrB4_B_B4/JB4 (Borderless): "733 1036"
*PaperDimension BrB4_B_S/JB4 (Borderless / Short Grain): "733 1036"
*PaperDimension Tabloid/Tabloid: "778 1210"
*PaperDimension BrLedger_S/Tabloid (Short Grain): "778 1210"
*PaperDimension BrLedger_B_Ledger/Tabloid (Borderless): "796 1228"
*PaperDimension BrLedger_B_S/Tabloid (Borderless / Short Grain): "796 1228"
*PaperDimension A4/A4: "585 829"
*PaperDimension BrA4_B/A4 (Borderless): "601 845"
*PaperDimension Letter/Letter: "602 779"
*PaperDimension BrLetter_B/US Letter (Borderless): "624 801"
*PaperDimension Legal/Legal: "602 995"
*PaperDimension Executive/Executive: "612 743"
*PaperDimension B5/JIS B5: "490 696"
*PaperDimension A5/A5: "410 582"
*PaperDimension A6/A6: "288 406"
*PaperDimension BrA6_B/A6 (Borderless): "302 430"
*PaperDimension PostC4x6/Photo: "278 419"
*PaperDimension BrPostC4x6_B/Photo (Borderless): "291 442"
*PaperDimension IndexC5x8/Index Card: "350 563"
*PaperDimension BrIndexC5x8_B/Index Card (Borderless): "363 586"
*PaperDimension PhotoL/Photo L: "242 347"
*PaperDimension BrPhotoL_B/Photo L (Borderless): "257 370"
*PaperDimension Photo2L/Photo 2L: "349 492"
*PaperDimension BrPhoto2L_B/Photo 2L (Borderless): "363 515"
*PaperDimension Postcard/Postcard 1: "273 406"
*PaperDimension BrHagaki_B/Postcard 1 (Borderless): "286 429"
*PaperDimension DoublePostcardRotated/Postcard 2 (Double): "410 554"
*PaperDimension EnvC5/C5 Envelope: "449 720"
*PaperDimension EnvDL/DL Envelope: "302 695"
*PaperDimension Env10/Com-10: "284 755"
*PaperDimension EnvMonarch/Monarch: "269 611"
*PaperDimension EnvYou4/JE4 Envelope: "287 735"
*%==== Custom Page Sizes ====================
*NonUIOrderDependency: 40 AnySetup *CustomPageSize
*VariablePaperSize: True
*LeadingEdge Short: ""
*MaxMediaWidth: "813"
*MaxMediaHeight: "1224"
*HWMargins: 8.5 8.5 8.5 8.5
*CustomPageSize True: " "
*End
*ParamCustomPageSize Width: 1 points 252 813
*ParamCustomPageSize Height: 2 points 360 1224
*ParamCustomPageSize WidthOffset: 3 points 0 0
*ParamCustomPageSize HeightOffset: 4 points 0 0
*ParamCustomPageSize Orientation: 5 int 0 3
*%=== Paper Feed================================
*OpenUI *BRInputSlot/Paper Source: PickOne
*OrderDependency: 13 AnySetup *BRInputSlot
*DefaultBRInputSlot: AutoSelect
*BRInputSlot AutoSelect/Auto Select: " "
*BRInputSlot Tray1/Tray 1: " "
*BRInputSlot Tray2/Tray 2: " "
*CloseUI: *BRInputSlot
*%==== Resolution Features =================================
*OpenUI *Resolution/Quality: PickOne
*OrderDependency: 14 AnySetup *Resolution
*DefaultResolution: 600x600dpi
*Resolution 150x150dpi/Fast: " "
*Resolution 300x300dpi/Fast Normal: " "
*Resolution 600x600dpi/Normal: " "
*Resolution 1200x1200dpi/Fine: " "
*Resolution 1200x2400dpi/Photo: " "
*Resolution 1200x6000dpi/Highest: " "
*CloseUI: *Resolution
*%=== MonoOrColor ================================
*OpenUI *BRMonoColor/Color/Grayscale: PickOne
*OrderDependency: 15 AnySetup *BRMonoColor
*DefaultBRMonoColor: Color
*BRMonoColor Color/Color: ""
*BRMonoColor Mono/Grayscale: ""
*CloseUI: *BRMonoColor
*%=== SlowDrying ================================
*OpenUI *BRSlowDrying/Slow Drying Paper: PickOne
*OrderDependency: 31 AnySetup *BRSlowDrying
*DefaultBRSlowDrying: OFF
*BRSlowDrying OFF/Off: ""
*BRSlowDrying ON/On: ""
*CloseUI: *BRSlowDrying
*%=== Media Type ================================
*OpenUI *BRColorMediaType/Media Type: PickOne
*OrderDependency: 16 AnySetup *BRColorMediaType
*DefaultBRColorMediaType: Plain
*BRColorMediaType Plain/Plain Paper: " "
*BRColorMediaType Inkjet/Inkjet Paper: " "
*BRColorMediaType BrotherGlossyR/Brother BP71 Photo Paper: " "
*BRColorMediaType BrotherGlossy/Brother BP61 Photo Paper: " "
*BRColorMediaType Glossy/Other Photo Paper: " "
*BRColorMediaType Transparencies/Transparencies: " "
*%BRColorMediaType HagakiAtena: " "
*%BRColorMediaType HagakiUra: " "
*CloseUI: *BRColorMediaType
*%=== Paper Thick ================================
*OpenUI *BRColorPaperThick/Paper Thickness: PickOne
*OrderDependency: 17 AnySetup *BRColorPaperThick
*DefaultBRColorPaperThick: Regular
*BRColorPaperThick Regular/Regular: ""
*BRColorPaperThick Thick/Thick: ""
*CloseUI: *BRColorPaperThick
*%=== Bi-DirKey ================================
*OpenUI *BRBiDir/Bi-Directional Printing: PickOne
*OrderDependency: 18 AnySetup *BRColorPaperThick
*DefaultBRBiDir: ON
*BRBiDir OFF/Off: ""
*BRBiDir ON/On: ""
*CloseUI: *BRBiDir
*%=== Reverse Printing ================================
*OpenUI *BRReverse/Reverse Printing: PickOne
*OrderDependency: 19 AnySetup *BRReverse
*DefaultBRReverse: OFF
*BRReverse OFF/Off: ""
*BRReverse ON/On: ""
*CloseUI: *BRReverse
*%=== Mirror Printing ================================
*OpenUI *BrMirror/Mirror Printing: PickOne
*OrderDependency: 20 AnySetup *BrMirror
*DefaultBrMirror: OFF
*BrMirror OFF/Off: " "
*BrMirror ON/On: " "
*CloseUI: *BrMirror
*%=== Jpeg Printing ================================
*OpenUI *BRJpeg/Data Transfer Mode: PickOne
*OrderDependency: 22 AnySetup *BRJpeg
*DefaultBRJpeg: Recommended
*BRJpeg Recommended/Recommended Setting: ""
*BRJpeg QualityPrior/Improved Print Quality: ""
*BRJpeg SpeedPrior/Improved Print Speed: ""
*CloseUI: *BRJpeg
*OpenGroup:Image Type
*%=== Color Mode ================================
*OpenUI *BRColorMatching/Color Mode: PickOne
*OrderDependency: 21 AnySetup *BRColorMatching
*DefaultBRColorMatching: Natural
*BRColorMatching Natural/Natural: ""
*BRColorMatching Vivid/Vivid: ""
*BRColorMatching None/None: ""
*CloseUI: *BRColorMatching
*%=== Half Tone Pattern ================================
*OpenUI *BRHalfTonePattern/Halftone Pattern: PickOne
*OrderDependency: 23 AnySetup * BRHalfTonePattern
*DefaultBRHalfTonePattern: Diffusion
*BRHalfTonePattern Diffusion/Diffusion: ""
*BRHalfTonePattern Dither/Dither: ""
*CloseUI: *BRHalfTonePattern
*CloseGroup:Image Type
*OpenGroup:Color Enhancement
*%=== True2Life ================================
*OpenUI *BRColorEnhancement/ Color Enhancement(True2Life): PickOne
*OrderDependency: 24 AnySetup *BRColorEnhancement
*DefaultBRColorEnhancement: OFF
*BRColorEnhancement OFF/Off: ""
*BRColorEnhancement ON/On: ""
*CloseUI: *BRColorEnhancement
*%=== Brightness ================================
*OpenUI *BRBrightness/ Brightness: PickOne
*OrderDependency: 25 AnySetup *BRBrightness
*DefaultBRBrightness: 0
*BRBrightness -20/-20: ""
*BRBrightness -19/-19: ""
*BRBrightness -18/-18: ""
*BRBrightness -17/-17: ""
*BRBrightness -16/-16: ""
*BRBrightness -15/-15: ""
*BRBrightness -14/-14: ""
*BRBrightness -13/-13: ""
*BRBrightness -12/-12: ""
*BRBrightness -11/-11: ""
*BRBrightness -10/-10: ""
*BRBrightness -9/-9: ""
*BRBrightness -8/-8: ""
*BRBrightness -7/-7: ""
*BRBrightness -6/-6: ""
*BRBrightness -5/-5: ""
*BRBrightness -4/-4: ""
*BRBrightness -3/-3: ""
*BRBrightness -2/-2: ""
*BRBrightness -1/-1: ""
*BRBrightness 0/0: ""
*BRBrightness 1/1: ""
*BRBrightness 2/2: ""
*BRBrightness 3/3: ""
*BRBrightness 4/4: ""
*BRBrightness 5/5: ""
*BRBrightness 6/6: ""
*BRBrightness 7/7: ""
*BRBrightness 8/8: ""
*BRBrightness 9/9: ""
*BRBrightness 10/10: ""
*BRBrightness 11/11: ""
*BRBrightness 12/12: ""
*BRBrightness 13/13: ""
*BRBrightness 14/14: ""
*BRBrightness 15/15: ""
*BRBrightness 16/16: ""
*BRBrightness 17/17: ""
*BRBrightness 18/18: ""
*BRBrightness 19/19: ""
*BRBrightness 20/20: ""
*CloseUI: *BRBrightness
*%=== Contrast ================================
*OpenUI *BRContrast/ Contrast: PickOne
*OrderDependency: 26 AnySetup *BRContrast
*DefaultBRContrast: 0
*BRContrast -20/-20: ""
*BRContrast -19/-19: ""
*BRContrast -18/-18: ""
*BRContrast -17/-17: ""
*BRContrast -16/-16: ""
*BRContrast -15/-15: ""
*BRContrast -14/-14: ""
*BRContrast -13/-13: ""
*BRContrast -12/-12: ""
*BRContrast -11/-11: ""
*BRContrast -10/-10: ""
*BRContrast -9/-9: ""
*BRContrast -8/-8: ""
*BRContrast -7/-7: ""
*BRContrast -6/-6: ""
*BRContrast -5/-5: ""
*BRContrast -4/-4: ""
*BRContrast -3/-3: ""
*BRContrast -2/-2: ""
*BRContrast -1/-1: ""
*BRContrast 0/0: ""
*BRContrast 1/1: ""
*BRContrast 2/2: ""
*BRContrast 3/3: ""
*BRContrast 4/4: ""
*BRContrast 5/5: ""
*BRContrast 6/6: ""
*BRContrast 7/7: ""
*BRContrast 8/8: ""
*BRContrast 9/9: ""
*BRContrast 10/10: ""
*BRContrast 11/11: ""
*BRContrast 12/12: ""
*BRContrast 13/13: ""
*BRContrast 14/14: ""
*BRContrast 15/15: ""
*BRContrast 16/16: ""
*BRContrast 17/17: ""
*BRContrast 18/18: ""
*BRContrast 19/19: ""
*BRContrast 20/20: ""
*CloseUI: *BRContrast
*%=== Red ================================
*OpenUI *BRRed/ Red: PickOne
*OrderDependency: 27 AnySetup *BRRed
*DefaultBRRed: 0
*BRRed -20/-20: ""
*BRRed -19/-19: ""
*BRRed -18/-18: ""
*BRRed -17/-17: ""
*BRRed -16/-16: ""
*BRRed -15/-15: ""
*BRRed -14/-14: ""
*BRRed -13/-13: ""
*BRRed -12/-12: ""
*BRRed -11/-11: ""
*BRRed -10/-10: ""
*BRRed -9/-9: ""
*BRRed -8/-8: ""
*BRRed -7/-7: ""
*BRRed -6/-6: ""
*BRRed -5/-5: ""
*BRRed -4/-4: ""
*BRRed -3/-3: ""
*BRRed -2/-2: ""
*BRRed -1/-1: ""
*BRRed 0/0: ""
*BRRed 1/1: ""
*BRRed 2/2: ""
*BRRed 3/3: ""
*BRRed 4/4: ""
*BRRed 5/5: ""
*BRRed 6/6: ""
*BRRed 7/7: ""
*BRRed 8/8: ""
*BRRed 9/9: ""
*BRRed 10/10: ""
*BRRed 11/11: ""
*BRRed 12/12: ""
*BRRed 13/13: ""
*BRRed 14/14: ""
*BRRed 15/15: ""
*BRRed 16/16: ""
*BRRed 17/17: ""
*BRRed 18/18: ""
*BRRed 19/19: ""
*BRRed 20/20: ""
*CloseUI: *BRRed
*%=== Green ================================
*OpenUI *BRGreen/ Green: PickOne
*OrderDependency: 28 AnySetup *BRGreen
*DefaultBRGreen: 0
*BRGreen -20/-20: ""
*BRGreen -19/-19: ""
*BRGreen -18/-18: ""
*BRGreen -17/-17: ""
*BRGreen -16/-16: ""
*BRGreen -15/-15: ""
*BRGreen -14/-14: ""
*BRGreen -13/-13: ""
*BRGreen -12/-12: ""
*BRGreen -11/-11: ""
*BRGreen -10/-10: ""
*BRGreen -9/-9: ""
*BRGreen -8/-8: ""
*BRGreen -7/-7: ""
*BRGreen -6/-6: ""
*BRGreen -5/-5: ""
*BRGreen -4/-4: ""
*BRGreen -3/-3: ""
*BRGreen -2/-2: ""
*BRGreen -1/-1: ""
*BRGreen 0/0: ""
*BRGreen 1/1: ""
*BRGreen 2/2: ""
*BRGreen 3/3: ""
*BRGreen 4/4: ""
*BRGreen 5/5: ""
*BRGreen 6/6: ""
*BRGreen 7/7: ""
*BRGreen 8/8: ""
*BRGreen 9/9: ""
*BRGreen 10/10: ""
*BRGreen 11/11: ""
*BRGreen 12/12: ""
*BRGreen 13/13: ""
*BRGreen 14/14: ""
*BRGreen 15/15: ""
*BRGreen 16/16: ""
*BRGreen 17/17: ""
*BRGreen 18/18: ""
*BRGreen 19/19: ""
*BRGreen 20/20: ""
*CloseUI: *BRGreen
*%=== Blue ================================
*OpenUI *BRBlue/Blue: PickOne
*OrderDependency: 29 AnySetup *BRBlue
*DefaultBRBlue: 0
*BRBlue -20/-20: ""
*BRBlue -19/-19: ""
*BRBlue -18/-18: ""
*BRBlue -17/-17: ""
*BRBlue -16/-16: ""
*BRBlue -15/-15: ""
*BRBlue -14/-14: ""
*BRBlue -13/-13: ""
*BRBlue -12/-12: ""
*BRBlue -11/-11: ""
*BRBlue -10/-10: ""
*BRBlue -9/-9: ""
*BRBlue -8/-8: ""
*BRBlue -7/-7: ""
*BRBlue -6/-6: ""
*BRBlue -5/-5: ""
*BRBlue -4/-4: ""
*BRBlue -3/-3: ""
*BRBlue -2/-2: ""
*BRBlue -1/-1: ""
*BRBlue 0/0: ""
*BRBlue 1/1: ""
*BRBlue 2/2: ""
*BRBlue 3/3: ""
*BRBlue 4/4: ""
*BRBlue 5/5: ""
*BRBlue 6/6: ""
*BRBlue 7/7: ""
*BRBlue 8/8: ""
*BRBlue 9/9: ""
*BRBlue 10/10: ""
*BRBlue 11/11: ""
*BRBlue 12/12: ""
*BRBlue 13/13: ""
*BRBlue 14/14: ""
*BRBlue 15/15: ""
*BRBlue 16/16: ""
*BRBlue 17/17: ""
*BRBlue 18/18: ""
*BRBlue 19/19: ""
*BRBlue 20/20: ""
*CloseUI: *BRBlue
*CloseGroup:Color Enhancement
*DefaultFont: Courier
*Font AvantGarde-Book: Standard "(001.006S)" Standard ROM
*Font AvantGarde-BookOblique: Standard "(001.006S)" Standard ROM
*Font AvantGarde-Demi: Standard "(001.007S)" Standard ROM
*Font AvantGarde-DemiOblique: Standard "(001.007S)" Standard ROM
*Font Bookman-Demi: Standard "(001.004S)" Standard ROM
*Font Bookman-DemiItalic: Standard "(001.004S)" Standard ROM
*Font Bookman-Light: Standard "(001.004S)" Standard ROM
*Font Bookman-LightItalic: Standard "(001.004S)" Standard ROM
*Font Courier: Standard "(002.004S)" Standard ROM
*Font Courier-Bold: Standard "(002.004S)" Standard ROM
*Font Courier-BoldOblique: Standard "(002.004S)" Standard ROM
*Font Courier-Oblique: Standard "(002.004S)" Standard ROM
*Font Helvetica: Standard "(001.006S)" Standard ROM
*Font Helvetica-Bold: Standard "(001.007S)" Standard ROM
*Font Helvetica-BoldOblique: Standard "(001.007S)" Standard ROM
*Font Helvetica-Narrow: Standard "(001.006S)" Standard ROM
*Font Helvetica-Narrow-Bold: Standard "(001.007S)" Standard ROM
*Font Helvetica-Narrow-BoldOblique: Standard "(001.007S)" Standard ROM
*Font Helvetica-Narrow-Oblique: Standard "(001.006S)" Standard ROM
*Font Helvetica-Oblique: Standard "(001.006S)" Standard ROM
*Font NewCenturySchlbk-Bold: Standard "(001.009S)" Standard ROM
*Font NewCenturySchlbk-BoldItalic: Standard "(001.007S)" Standard ROM
*Font NewCenturySchlbk-Italic: Standard "(001.006S)" Standard ROM
*Font NewCenturySchlbk-Roman: Standard "(001.007S)" Standard ROM
*Font Palatino-Bold: Standard "(001.005S)" Standard ROM
*Font Palatino-BoldItalic: Standard "(001.005S)" Standard ROM
*Font Palatino-Italic: Standard "(001.005S)" Standard ROM
*Font Palatino-Roman: Standard "(001.005S)" Standard ROM
*Font Times-Bold: Standard "(001.007S)" Standard ROM
*Font Times-BoldItalic: Standard "(001.009S)" Standard ROM
*Font Times-Italic: Standard "(001.007S)" Standard ROM
*Font Times-Roman: Standard "(001.007S)" Standard ROM
*Font ZapfChancery-MediumItalic: Standard "(001.007S)" Standard ROM
*Font ZapfDingbats: Special "(001.004S)" Special ROM
*Font Symbol: Special "(001.007S)" Special ROM
*Font Alaska: Standard "(001.005)" Standard ROM
*Font AlaskaExtrabold: Standard "(001.005)" Standard ROM
*Font AntiqueOakland: Standard "(001.005)" Standard ROM
*Font AntiqueOakland-Bold: Standard "(001.005)" Standard ROM
*Font AntiqueOakland-Oblique: Standard "(001.005)" Standard ROM
*Font ClevelandCondensed: Standard "(001.005)" Standard ROM
*Font Connecticut: Standard "(001.005)" Standard ROM
*Font Guatemala-Antique: Standard "(001.005)" Standard ROM
*Font Guatemala-Bold: Standard "(001.005)" Standard ROM
*Font Guatemala-Italic: Standard "(001.005)" Standard ROM
*Font Guatemala-BoldItalic: Standard "(001.005)" Standard ROM
*Font LetterGothic: Standard "(001.005)" Standard ROM
*Font LetterGothic-Bold: Standard "(001.005)" Standard ROM
*Font LetterGothic-Oblique: Standard "(001.005)" Standard ROM
*Font Maryland: Standard "(001.005)" Standard ROM
*Font Oklahoma: Standard "(001.005)" Standard ROM
*Font Oklahoma-Bold: Standard "(001.005)" Standard ROM
*Font Oklahoma-Oblique: Standard "(001.005)" Standard ROM
*Font Oklahoma-BoldOblique: Standard "(001.005)" Standard ROM
*Font Utah: Standard "(001.005)" Standard ROM
*Font Utah-Bold: Standard "(001.005)" Standard ROM
*Font Utah-Oblique: Standard "(001.005)" Standard ROM
*Font Utah-BoldOblique: Standard "(001.005)" Standard ROM
*Font UtahCondensed: Standard "(001.005)" Standard ROM
*Font UtahCondensed-Bold: Standard "(001.005)" Standard ROM
*Font UtahCondensed-Oblique: Standard "(001.004)" Standard ROM
*Font UtahCondensed-BoldOblique: Standard "(001.005)" Standard ROM
*Font BermudaScript: Standard "(001.005)" Standard ROM
*Font Germany: Standard "(001.005)" Standard ROM
*Font SanDiego: Standard "(001.005)" Standard ROM
*Font US-Roman: Standard "(001.005)" Standard ROM
*UIConstraints: *BRColorMediaType Plain *Resolution 1200x2400dpi
*UIConstraints: *BRColorMediaType Plain *Resolution 1200x6000dpi
*UIConstraints: *BRColorMediaType Inkjet *Resolution 150x150dpi
*UIConstraints: *BRColorMediaType Inkjet *Resolution 300x300dpi
*UIConstraints: *BRColorMediaType Inkjet *Resolution 600x600dpi
*UIConstraints: *BRColorMediaType Inkjet *Resolution 1200x6000dpi
*UIConstraints: *BRColorMediaType BrotherGlossyR *Resolution 150x150dpi
*UIConstraints: *BRColorMediaType BrotherGlossyR *Resolution 300x300dpi
*UIConstraints: *BRColorMediaType BrotherGlossyR *Resolution 600x600dpi
*UIConstraints: *BRColorMediaType BrotherGlossy *Resolution 150x150dpi
*UIConstraints: *BRColorMediaType BrotherGlossy *Resolution 300x300dpi
*UIConstraints: *BRColorMediaType BrotherGlossy *Resolution 600x600dpi
*UIConstraints: *BRColorMediaType Glossy *Resolution 150x150dpi
*UIConstraints: *BRColorMediaType Glossy *Resolution 300x300dpi
*UIConstraints: *BRColorMediaType Glossy *Resolution 600x600dpi
*UIConstraints: *BRColorMediaType Transparencies *Resolution 150x150dpi
*UIConstraints: *BRColorMediaType Transparencies *Resolution 300x300dpi
*UIConstraints: *BRColorMediaType Transparencies *Resolution 1200x2400dpi
*UIConstraints: *BRColorMediaType Transparencies *Resolution 1200x6000dpi
*UIConstraints: *BRColorMediaType Transparencies *PageSize BrA3_B_S
*UIConstraints: *BRColorMediaType Transparencies *PageSize BrA3_B_A3
*UIConstraints: *BRColorMediaType Transparencies *PageSize BrB4_B_B4
*UIConstraints: *BRColorMediaType Transparencies *PageSize BrB4_B_S
*UIConstraints: *BRColorMediaType Transparencies *PageSize BrLedger_B_Ledger
*UIConstraints: *BRColorMediaType Transparencies *PageSize BrLedger_B_S
*UIConstraints: *BRColorMediaType Transparencies *PageSize BrA4_B
*UIConstraints: *BRColorMediaType Transparencies *PageSize BrLetter_B
*UIConstraints: *BRColorMediaType Transparencies *PageSize BrA6_B
*UIConstraints: *BRColorMediaType Transparencies *PageSize BrPostC4x6_B
*UIConstraints: *BRColorMediaType Transparencies *PageSize BrIndexC5x8_B
*UIConstraints: *BRColorMediaType Transparencies *PageSize BrPhotoL_B
*UIConstraints: *BRColorMediaType Transparencies *PageSize BrPhoto2L_B
*UIConstraints: *BRColorMediaType Transparencies *PageSize BrHagaki_B
I would like to mention also that the Brother rpm diver package install in tumbleweed but can’t be detected.
it fails to build the needed ppd file. The one that work is their linux-brprinter-installer which tumbleweed detect the printer and scanner and work but it spit warning also during install. Below is from the installer
/bin/bash linux-brprinter-installer-2.2.6-0
Input model name ->MFC5890CN
You are going to install following packages.
mfc5890cnlpr-1.1.2-2.i386.rpm
mfc5890cncupswrapper-1.1.2-2.i386.rpm
brscan3-0.2.13-1.x86_64.rpm
brscan-skey-0.3.4-0.x86_64.rpm
OK? [y/N] ->Y
ln: failed to create symbolic link '/etc/init.d/cupsys': No such file or directory
ln: failed to create symbolic link '/etc/init.d/cups': No such file or directory
ln: failed to create symbolic link '/etc/init.d/lpd': No such file or directory
ln: failed to create symbolic link '/etc/init.d/lprng': No such file or directory
rpm -ihv --nodeps --replacefiles --replacepkgs --ignorearch mfc5890cnlpr-1.1.2-2.i386.rpm
Verifying... ################################# [100%]
Preparing... ################################# [100%]
Updating / installing...
1:mfc5890cnlpr-1.1.2-2 ################################# [100%]
rpm -ihv --nodeps --replacefiles --replacepkgs --ignorearch mfc5890cncupswrapper-1.1.2-2.i386.rpm
Verifying... ########################################
Preparing... ########################################
Updating / installing...
mfc5890cncupswrapper-1.1.2-2 ########################################
lpadmin: Printer drivers are deprecated and will stop working in a future version of CUPS.
#
mfc5890cnlpr
semanage fcontext -a -t cupsd_rw_etc_t /usr/local/Brother/Printer/(.*/)?inf(/.*)?
ValueError: File spec /usr/local/Brother/Printer/(.*/)?inf(/.*)? conflicts with equivalency rule '/usr/local /usr'; Try adding '/usr/Brother/Printer/(.*/)?inf(/.*)?' instead
restorecon -R /usr/local/Brother/Printer
semanage fcontext -a -t bin_t /usr/local/Brother/Printer/(.*/)?inf/brprintconf(.*)?
ValueError: File spec /usr/local/Brother/Printer/(.*/)?inf/brprintconf(.*)? conflicts with equivalency rule '/usr/local /usr'; Try adding '/usr/Brother/Printer/(.*/)?inf/brprintconf(.*)?' instead
restorecon -R /usr/local/Brother/Printer
semanage fcontext -a -t bin_t /usr/local/Brother/Printer/(.*/)?lpd(/.*)?
ValueError: File spec /usr/local/Brother/Printer/(.*/)?lpd(/.*)? conflicts with equivalency rule '/usr/local /usr'; Try adding '/usr/Brother/Printer/(.*/)?lpd(/.*)?' instead
restorecon -R /usr/local/Brother/Printer
semanage fcontext -a -t bin_t /usr/local/Brother/Printer/(.*/)?cupswrapper(/.*)?
ValueError: File spec /usr/local/Brother/Printer/(.*/)?cupswrapper(/.*)? conflicts with equivalency rule '/usr/local /usr'; Try adding '/usr/Brother/Printer/(.*/)?cupswrapper(/.*)?' instead
restorecon -R /usr/local/Brother/Printer
semanage fcontext -a -t bin_t /usr/local/Brother
ValueError: File spec /usr/local/Brother conflicts with equivalency rule '/usr/local /usr'; Try adding '/usr/Brother' instead
restorecon -R /usr/local/Brother
semanage fcontext -a -t bin_t /opt/brother
File context for /opt/brother already defined, modifying instead
restorecon -R /opt/brother
semanage fcontext -a -t cupsd_rw_etc_t /etc/opt/brother
restorecon -R /etc/opt/brother
restorecon -RFv /usr/lib/cups/filter
Relabeled /usr/lib/cups/filter/brlpdwrappermfc5890cn from unconfined_u:object_r:bin_t:s0 to system_u:object_r:bin_t:s0
setsebool -P cups_execmem 1
Lastly the test print if it is relevant it says:
Media Limits: 0.12 x 0.12 to 8.24 x 10.69 inches.
Some ideas:
Legal is already the default in the PPD). Find it with…find /usr/local/Brother /opt/brother /usr/Brother -iname "*mfc5890cn*rc" 2>/dev/nullPageSize= line set to Letter, edit it (as root) to Legal and retest.Based on a similar topic…
find /usr/local/Brother /opt/brother /usr/Brother -iname "brprintconf*" 2>/dev/nullsudo /path/to/brprintconf***** -pt LegalIf the above do not help, I wonder if worth trying a gutenprint driver (for a similar Brother inkjet model) instead? Other than that I’m out of ideas.
Edit: Forget 2 I couldn’t get this to work interactively (I have a an old DCP-7055 laser printer model and brprintconflsr3 installed).
@deano_ferrari Lots a lotsa thanks for the guidance/help as usual you’re the savior
So I opened the /usr/local/Brother/Printer/mfc5890cn/inf/brmfc5890cnrc.
Though the brother printer is physically configured to legal paper as default and the system configuration is set legal paper as default and the application to print the image is set to legal size, the brmfc5890cnrc is set to letter size paper.
I change the brmfc5890cnrc to default to legal size paper and did a test print and the result is as expected. It printed in legal size.
Downside of this is I have to manually change to letter size or ledger(tabloid) by hand just to get the proper printed result .
A t least I can still use this old printer for some especial type of printing.
Once again thanks for the help, you save my day and made this old printer great again.
@deano_ferrari
Here is the printed image result in legal size
Note that the drawing was printed in legal size but it printed in letter size which you can see that it was cut almost a quarter of the legal paper lenght.
The black bold line on top of the image that extend from end to end of the legal size paper is the result of the test print after changing the paper size in brmfc5890cnrc.
So, I’m not clear on if this is solved or something more to examined? In your last post, the image is still being rendered too small?
The outer rectangular white background is just a background when I converted the image to jpeg.
The legal size paper is the rectangle with bold black line on four corners .
Ok, so all good now?
@deano_ferrari Yep it’s all good now. Lots of thanks for the help.
This topic was automatically closed 7 days after the last reply. New replies are no longer allowed.
